SC-6162TS
Mode:
Printhead Epson I3200-E1/A1
Head Quantity 2
Colors CMYK
Printing Resolution 3200
RIP software Maintop,FlexiPRINT,ONYX,etc.
We're here to help:Easy ways to get the answers you need.
* Heating in the front, middle and rear makes the material heated more evenly, increases the ink absorption, and the printing effect is more vivid.
* Adopt the sub-tank ink supply system to ensure the stability of long-term output ink supply.
* Variable voltage, the control software can automatically change the printhead voltage according to diferent temperatures to improve the problems of ink missing.
* Inteligent design, compatible with printing software such as Maintop, FlexiPRINT, ONYX, etc, is more convenient to use.
* Equipped with a Chinese and English operation interface, both physical buttons and computer can control the machine, which is convenient for operation.
SC-6160S/SC-6162TS | ||||||
Printhead | Type: Epson I3200-E1 Number of Nozzles: 3200(1PC) Resolution: 3200DPI Head Clean: Auto cleaning, flash and Moisturizing |
Type: Epson I3200-A1 Number of Nozzles: 3200(1PC) Resolution: 3200DPI Head Clean: Auto cleaning, flash and Moisturizing |
||||
Quantity | 1 | 2 | 1 | 2 | ||
Print Speed *Tested on linear printing without feather function |
2pass | 30㎡/h | 80㎡/h | 2pass | 30㎡/h | 80㎡/h |
3pass | 25㎡/h | 55㎡/h | 4pass | 25㎡/h | 55㎡/h | |
4pass | 20㎡/h | 40㎡/h | 6pass | 20㎡/h | 40㎡/h | |
6pass | 15㎡/h | 30㎡/h | 8pass | 15㎡/h | 30㎡/h | |
Data Transmission Port | Giga-bit Ethernet Port | |||||
Print Width | 1600mm | |||||
Ink Type | Type: Water-based ink(Dye or Pigment), Eco Solvent Ink Color:CMYK |
|||||
Print Media | Indoor Advertising Material, Transfer Paper, PP Vinyl,Flex Banner,Canvas Banner, etc. | |||||
Rip Software | Maintop,FlexiPRINT,ONYX,etc. | |||||
Image Format | JPG, TIFF, BMP, PDF, etc. | |||||
Computer System | Win7,Win10 | |||||
Transmit Port | Network Port | |||||
Computer Cofigiration | Hard Disk: 500G or more, GPU: ATI Mobility Radeon, Memory: 4G or above CPU: Intel 4 I5 processor or above |
|||||
Optional Device | Heat System: Extra Dryer Device | |||||
Working Environment | Temp.:15℃-30℃, Humidity: 35℃-65℃ | |||||
Power Supply | 50/60HZ, 220V, 5A | |||||
Dimensions | 2566x662x1302mm | |||||
Machine Weight | 240kg |
